Framebuilder Tooling – Using a Milling Machine

Framebuilder Tooling – Using a Milling Machine

A Milling Machine is usually the second major machine tool any aspiring metalworker will obtain, after a lathe. More correctly known as a vertical mill as horizontal mills do exist. Whereas a lathe mainly turns objects in a circle, the milling machine will make objects square and cut slots as well as performing tasks that can also be done on a lathe such as drilling and tapping (being more flexible for this), boring holes and sawing (using a ‘slitting saw’) and mitering tubes.
 Basically it consists of a drill mounted on a column which can be moved up and down, pretty much the same as a pillar drill. The head is wound down slowly and has an accurate depth scale on the operating handle. There is also a plunge section as you would find on a pillar drill with a large handle which can be used for rapid drilling but is locked out for more subtle milling operations. The column can often be tilted from side to side to enable cutting at an angle but in practice this is not very useful and it is usually better to mount the work at an angle. The mill can be used as a drill press. Some mills are sold as mill/drills but I am not sure of the difference. Drills can be mounted in a drill chuck but other tools are best mounted in a collet chuck system which is more accurate and secure. The drill head itself can only move up and down, so the shaping of the metal is achieved by moving the table in two axes, against the milling cutters of which there are several types. Collet chucks and the like are usually attached to the mill head using a morse taper. These have a tapped hole in the top which is to further secure them in the drilling head with a threaded bar. Unfortunately a lot of potentially interchangeable lathe tools have a tang (a projecting bit of metal) which is to facilitate their ejection from the lathe tailstock. This means they will not fit into the mill head. I am mystified as to why tooling manufacturers do not make interchangeable tools.
fullsizeoutput_6c6 fullsizeoutput_6c4

Femi 782XL Metal Cutting Bandsaw – Review

Femi 782XL Metal Cutting Bandsaw – Review

I have wanted a bandsaw for some time but have been deterred by their size and weight in as much as one would have needed a permanent space allocating in the workshop, which I do not have! I then discovered the Femi portable saws, the 782XL being the smallest and only weighing 16kg. It will cut solid metal up to 41/2 inch diameter at a reasonable speed and the blade requires no lubrication during cutting. It stores away under my bench.
I also obtained one of the matching tables which folds flat so also takes up no space. Although the table is sold as matching the bandsaw I could only match up one hole to slip a bolt through to make sure it is stable in use when being used as a table saw. It seems perfectly stable when used otherwise resting on a bench or the floor.
IMG_3639 fullsizeoutput_690

Extras available are a small cutting table which attaches easily by clamping in the material clamp and a quadrant kit which in retrospect I probably will not use as it appears to be designed to help feed a large sheet at an angle, the size of which I cannot envisage using. Oddly Femi do not supply a fence guide which I think you really do need when cutting small pieces on the table. It is possible to purchase generic fences from places such as Axminster but I do not know for sure if they will fit.

Tube Mitering on a Lathe – Updated

Tube mitering is a fundamental part of custom frame building and I am sure there is always a need to be able to produce good results by hand and eye. Paper templates are a boon for speeding up the process and increasing accuracy but I decided to see how I would get on with some form of automation for the process. A milling machine, lathe or tube notcher can all be used but as I already have a lathe this seemed the way forward. I have described elsewhere making the tube blocks to enable this. My lathe is small with 500mm between centres.
I have obtained several Coba-Tech hole saws from Stakesy’s metalwork machinery suppliers (https://www.stakesys.co.uk/hole-punches-hole-saws/hole-saws-arbors/coba-tech-10-tpi-fine-tooth-holesaws). These are fine tooth saws as opposed to the more usual coarse tooth saws I have used in the past. For cutting good mitres in fine tubes I would say these are essential and Stakesy’s were the only supplier I could find. They also sell some tube notchers which are designed to be used with a conventional drill but I have no experience of using these.

Coarse and fine tooth saws (fine on the right)

Coarse and fine tooth saws (fine on the right)

A Guide to Brazing and Soldering

A Guide to Brazing and Soldering

A Guide to Brazing and Soldering by Keith Hale, self published and available from CuP Alloys:  www.cupalloys.co.uk
fullsizeoutput_650fullsizeoutput_651
Last Weekend I visited the annual Midlands Model Engineering Exhibition in Warwickshire. Whilst having no ambition to build complex working models you have to admire them. My interest is in the fact that a lot of the engineering advice and guidance, and books I have used come through these hobbies and the number of tool suppliers that supply them. I managed to buy even more tools whilst I was there but the highlight was a lecture by Keith Hale who was introducing his new book. The subject “Everything You wanted to know about Silver Soldering but were afraid to ask.” The talk was excellent and having purchased the book at the show at a discount price, I can now confirm the book, which expands on his talk, is excellent too and I can thoroughly recommend it to frame builders. Whilst concentrating on Silver Soldering, which is in any case of great interest to me, it also covers the use of brass and other metals. For me it answers many questions, explained some things and gave me ideas as to how I can significantly improve my practice. The information is presented in a non-technical way and very logical order.
CuP Alloys, originally founded by Keith, supplies mainly silver solder and will do so in small quantities. They have solders equivalent to Sif products, my previous choice, and at competitive prices but they do not sell any lower melting point bronze rods to compare with Sif 101, or any Silver Solders that have the properties of Cycle Design Fillet Pro. Still I would definitely visit their website and buy this book which retails at £17-50.

Stephen Hilton 23/10/17

Tube Bending and Panana Budget Tube Bender Review

Tube Bending and Panana Budget Tube Bender Review

Tube bending is something I avoid, however there are times when it is necessary. Some framebuilders do it as a feature of their work but I tend to only use bent tubes when it is necessary to solve a clearance problem as with the child’s first pedal bike. I purchased this bender for the princely sum of £90 from an Ebay retailer who I guess is based in China but had stocks in the UK. The brand may be a red herring as I suspect it is one of those tools turned out by a Chinese factory under different names. Indeed Stakesy’s have what looks to be an identical bender available on their site for £165, though they were out of stock when I ordered mine: https://www.stakesys.co.uk/tube-pipe-benders/manual-tube-benders/sta137-buzz-bench-top-manual-tube-bender.

Child’s First Pedal Bike

Child’s First Pedal Bike

Having previously made a balance bike I now need to follow this up with a pedal bike. This has proved to be quite a challenge. Having come up with a design from the child’s existing measurements using BikeCad I needed 14 inch wheels. These are almost impossible to find as is a suitably small chain set. Eventually after much searching I decided to buy a donor bike for some of the parts. I wasn’t able to find a suitable one in a hurry on Ebay so headed to my local Argos (other retailers are available) and purchased  very heavy 14 inch bike. Like all similar bikes it has very fat tyres and weird caliper brakes that make contact on the undersurface of the rim. The chainset is basic press fit with cheap bearings and lightweight 1/8 inch chain. Surprisingly the bottom bracket was a standard adult width and the dimensions of the bottom bracket very close to a standard PF86, though not quite. Having started down this road it looks like I will have to bite the bullet and use the wheels, chainset and brakes and maybe the chainguard.

Bespoke 2017

Bespoke 2017

An excellent display of custom building again this year with many highlights. I doubt if I spotted them all.
Lugs are back
Although they never went away it seemed to me that there were more lugged bikes than ever this year and in particular with stainless lugs, my own favourite. The standard of stainless steel polishing also seems to have gone up, though once again the bikes displayed by Darrell McCulloch (Llewellyn Custom Bicycles) were on another level.
fullsizeoutput_5c8 fullsizeoutput_5c7 fullsizeoutput_5c6 fullsizeoutput_5c5 fullsizeoutput_5c4 fullsizeoutput_5c3 fullsizeoutput_5c2fullsizeoutput_5c9

There was some brushed stainless in evidence, not something I have tried and I suspect difficult to do well.

953 /Carbon Semi-Lugged Road Bike

953 /Carbon Semi-Lugged Road Bike

I have previously built a Road bike using Reynolds 953 and Llewellyn lugs with a Dedacciai carbon fibre rear triangle. This was something of an experiment as, whilst it was a standard thing to do, I was unable to find any real information about how to go about it, especially in relation to the glueing process. I have now been riding the bike I built for two and a half years and have had no issues with it other than a minor problem I will mention later. Using the experience I now have I am going to build a similar frame. This will again use 953 oversize  main tubes (35.9,31.7,31.7) with stainless Llewellyn lugs. The rear triangle  is supplied with it’s own bottom bracket so this has to be fillet brazed in. Although the rear triangle is supposed to be a  Dedacciai Firebox as before, from Ceeway, it is a slightly different shape from the previous one and is marked “Black Box and Black Tail”.

Introduction to Milling – another Axminster skill centre course

Introduction to Milling – another Axminster skill centre course

At the end of November I attended a two day course as an introduction to using a milling machine. This will be another machine to complement the lathe in producing custom bicycle parts. Now I will be able to make things that are not only round, which is the limitation of a lathe. The milling machine enables the cutting of shapes that are square or curved or stepped, together with slots, so I should be able to make various types of dropouts and no doubt other things. It can also be used to mitre tubes. The course costs £275, including lunch and refreshments, a slight increase on last years fees. There were 4 students to one tutor and I was lucky enough to be taught by Bob Rolph who had previously taught the small lathe course.
Students use the Axminster SX3 machines for the course (other machines are available) and there is no hard sell to purchase Axminster’s own products.

Disc Brake Fixtures on Kickstarter – UPDATE 2

Disc Brake Fixtures on Kickstarter – UPDATE 2

Eric Meinert, from Canada, has just launched a Kickstarter project to fund his POST MOUNT disc brake fixture. Suitable for both frame and fork as with previous fixtures, and suitable for both 140mm and 160mm rotors. The fixture can be ordered by pledge on Kickstarter: https://www.kickstarter.com/projects/4608648/bicycle-post-mount-disc-brake-jig. It will subsequently available from his Incepi website.

This fixture now complements his other available fixtures which are available from his INCEPI website at:  http://incepi.myshopify.com
There is an ISO disc brake tab fixture, below, which I purchased through a previous Kickstarter launch.
fdc5d88315fddee65be9afe7980f3146_large de1408012ce5c9cf03fc4e447e26843f_large

IMG_2133
Additionally there is now a FLAT MOUNT fixture which I understand is likely to become the accepted standard for road bikes. I think the price for the fixtures is very reasonable despite having to import them from Canada: effects of Brexit not withstanding!
FullSizeRender_6_copy_large
I have no experience of flat mount fitting on steel frames but The only commercial supplier I could find of the flat mounts themselves was Paragon Machineworks in the USA. However when I was at Bespoke 2016, Bear Bikes in Leighton Buzzard did have some on display and although they are not advertised as such I am sure they can supply them.
